Automatic Manual Mesh Panel Welding Machine For Fence And
Construction
Main parameters
| Wire diameter | 2.5~6mm | Line wire form | pre-cut wire |
| Weft wire distance | 25--300mm | Weft wire form | pre-cut wire |
| Line wire distance | 50~300mm | Rated voltage | 380V 50Hz |
| Welding net width | 2500mm | Rated power | 6*125KVA |
| Welding speed | 45--60times/min | Overall dimention | 8*3.2*1.7m |
| Line wire No. | 51 | Wire net length | 6000mm |
1. This kind of wire mesh welding machine is our latest developed
reinforcing mesh welding machine.
2. The line wire and the weft wire of wire mesh welding machine are
pre-straight and pre-cut.
3. The line wire is feeding by the servo motor ,pulling the wire
net by the servo motor auto.
4. The wire mesh welding machine welding power comes from the
cylinders. It’s easy to control the welding pressure .
5. The weft wire of wire mesh welding machine feeding from the
multi hopper which capacity is more over ten times than the
traditional hopper.
6. The new wire mesh welding machine added the bear wire net and
carry equipment that makes the working more convenience .
7. The welding part of wire mesh welding machine is used the
springiness input wire trunking that makes the welding copper use
for long time.
8. This wire mesh welding machine adopts synchronous control
technique. The cent-control and welding time are composed of PLC
program system. The input front-panel is touch screen , the operate
is more intelligent and reasonable.
