Fully automatic pvc powder coating line for welding mesh fence and
pots
Description
This Powder Coating Line is used to provide an anti-corrosive
surface treatment for mesh fence, wire mesh fence, perforated metal
mesh, sheet, expanded metal mesh fence, fence sheet, fence mesh,
isolated gate and matched posts. As one kind of safety security,
the finished products are great to be fencing for highway, railway,
airport and so on.
Main technical parameters:
(1) Max. size of mesh fence: 4000mm long * 2500mm wide
(2) Coating speed: 40~60 sheets per hour
(3) Power consumption: installed capacity 60kw, average power 50kw
(4) Oil consumption: 2200-3000m3/24h
(5) Water consumption: 0.6 -1.2 m3/h (circulating water)
(6) Plant request size(L*W*H): ≥50000mm *14000mm * 5000mm
Process flow
Manual feeding - Pre-heating - Auto powder immersion - Curing -
Coated workpiece cooling - Manual discharging - Manual shaping
correction - Quality control - Final package
Composition of a complete coating line:
(1) Auto eletrical pre-heating & curing furnace;
(2) Auto coating powder up-and-down device, vibration generator,
fluidized bed;
(3) Hanging delivery system, special hanger for workpiece;
(4) Power supply control equipment, auto program control.
Machine is installed and commissioned by technicians. Testing cost,
travel, accommodation and meal expenses are payable by the
customer, the customer will provide local engineers and staff to
support the installation.
